|RG-SNC Basic Component
|Deployed based on pure B/S architecture. No client installation is required for users. Enable system access using any standard browsers.
|Support system restart and shutdown using web browser; Monitor server CPU, memory and network card status; Support retrieval of system operation logs via the web page.
|Support file licensing mode.
|Support integration of authentication-free feature of the network control interface with customer system.
|Support forwarding of network management alert, syslog, trap to customer system.
|Support integration with web services, or network management properties, alerts, performance data.
|Unified Wired and Wireless Management
|Support unified wired and wireless management on devices such as routers, switches, firewalls and WLAN by modularization.
|Support low-threshold bandwidth monitoring, remote power management and flexible icon management.
|Support wireless networking for the ease of future unified management and surveillance on wired and wireless devices.
|Support a variety of device management features. Include a good presentation and basic operating features for creating, deleting or editing device interfaces and data.
|Support batch software upgrade for multiple devices.
|Support a graphical presentation of the actual physical boards, line cards and ports. Support operation directly on the page.
|Support auto software upgrade checking. Support batch software upgrade.
|Support management based on hierarchy and categorization. Enable users to set status of one device or multiple devices to be read-only, writable or hidden. For hidden devices, markings are required to be shown on topology.
|Support editing of device information such as organization name, purchase date, warranty validity, etc.
|Device Configuration Management
|Support auto retrieval of configuration files on a regular basis and synchronization to management server. Support comparison of the collected data with the previous configuration files. Notify the administrator via email if any difference is found.
|Support auto discovery of Layer 2 and Layer 3 network devices. Support auto topology formation.
|Support discovery of WAN link topology. Support adding virtual nodes such as ‘building’, ‘cloud’, etc.
|Support viewing of a customized topology by a designated IP range or through chosen devices. In every such topology diagram, only matching devices are shown.
|Support auto discovery of routing topology, showing routing relation among devices in the system network layer.
|Support export of the current topology.
|Support dynamically update network topology based on device and link status data collected in real time.
|Support dual-link STP detection. The topology shows real-time status of both links respectively.
|Support topology display in full screen.
|Under the full screen mode, proactively send topology alerts in an animated presentation.
|In the event of operating status changes or alerts triggered, the relative nodes in the topology can be highlighted in real time.
|Support VSU topology and show the many-to-one virtualization in the topology in real time. Support direct viewing of links and status of multiple device members on the topology.
|Support image upload for background customization.
|Support image upload for node icon customization.
|Support traffic topology of the Weather Map mode.
|The product should be built-in with a variety of common alert categories. Support alert category customization based on the actual demand whenever necessary. Provide a minimum of 10 common syslog alert customization lists.
|The product should be built-in with a variety of common alert categories. Support alert category customization based on the actual demand whenever necessary. Provide a minimum of 50 pre-defined trap alert customization lists.
|Support setting performance indicator threshold as general, important or very important. When the indicator exceeds the threshold, respective alert will be sent based on the threshold value.
|Support traffic lower limit alert. When the traffic is lower than the designated threshold, alert will be sent.
|Support maintenance schedule for designated devices. Within such period maintenance, no alert will be sent.
|Key Link Detection
|Support intelligent real-time detection for key links. Upon status changes, quickly locate failure. Support multiple alert modes to notify the administrator to resume network service as soon as possible.
|Customize task for long-term surveillance of the network performance. Support report generation on a real-time or periodic basis.
|Support report creation, search, editing, deletion. Support report online viewing, import/export, etc. Support periodic export and regular publishing.
|Support history report search.
|Interface Mapping Management
|Support regular collection of user devices IP, MAC, port mapping table. When there are abnormalities found in the mapping table, alert administrator as an event immediately.
|Integration of Topology and User Information
|To protect customer’s early investment, support registration integration with SAM/SMP. Support searching of online user table including user name, IP address, MAC address, etc.
|The product should support standard SNMP MIP management base. Support management on mainstream vendor standard MIB device.
|The product should be compliant with the related rules under Administration of Software Products Regulation.
With national software copyright registration certificate.
